Power source |
AC 110 240 V 50/60 Hz (MD-DR480H),
AC 230 V 50/60 Hz (MD-DR470H)
DC 1.2 V (Rechargeable Ni-MH battery: AD-N55BT x 1), DC
1.5 V (AA battery x 1), DC 5.0 V (AC adaptor) |
Power consumption |
0.15 A with AC adaptor (MD-DR480H),
7 W with AC adaptor (MD-DR470H) |
Error correction |
ACIRC (Advanced Cross Interleave Reed-Solomon
Code) |
Audio compression |
ATRAC/ATRAC3 (Adaptive Transform Acoustic
Coding), 24-bit computed type |
Frequency response |
20 to 20,000 Hz (±3 dB) |
Wow and flutter |
Below measurable limits (±0.001%
W) |
D/A converter |
1-bit
converter |
Modulation system |
EFM (Eight to Fourteen Modulation) |
Terminals |
Earphones, Line/Optical input, Mic.
input, DC input |
Dimensions |
78.9 (W) x 17.8 (H) x 71.9 (D) mm
|
Weight |
140 g with rechargeable battery |
Included accessories |
Recharging station (MD-DR480H), LCD
remote control, Ear-fit type earphones*, Inner-ear
type earphones, Rechargeable Ni-MH battery, AC adaptor,
RCA lead, Optical digital cable, PC-Link cable, Conversion
cable (4-pole to 3-pole), Carrying bag |
Optional accessories |
Rechargeable battery: AD-N55BT, Car
adaptor: AD-CA55X, Cassette adaptor: AD-CT14, MD-to-MD edit cable: AD-M5AC, Tie-pin microphone: MC-TP2
|
|
|
|
|
* |
In some regions, ear-fit type
headphones are not included with the MD-DR470H. |
|
|
|
|
|
