REPLACING THE TONER COLLECTION CONTAINER

The toner collection container collects excess toner that is produced during printing. When the toner collection container becomes full, the message "Replace toner collection container." will appear.
Replace the toner collection container as instructed by the message in the touch panel.
When the key is tapped, instructions for replacing the toner collection container will appear. Follow the instructions. When the toner collection container is replaced, the message will automatically disappear.

Warning

  • Do not throw the toner collection container into a fire. Toner may fly and cause burns.
  • Store the toner collection container out of the reach of small children.

Caution

Do not touch the internal cords or connectors.

Open the cover for toner collection container.

Remove the toner collection container.

Hold the handle of the toner collection container and slowly remove it toward you.

Place the toner collection container on a flat surface and close the cap.

Place a sheet of paper such as newspaper on the surface before placing the toner collection container.
  • Keep the toner collection container in an upright position without collapsing it.
  • Do not point the holes down as used toner will spill out.
  • Do not throw away the removed toner collection container, instead place it in the plastic bag provided and keep it in the box in which it was packed.

Install a new toner collection container.

Hold the handle of the toner collection container and push it all the way in.

Close the cover for toner collection container.
