This function reverses black
and white in a copy to create a negative image. This function can
only be used for black and white copying.
Originals with large black areas (which use a large amount
of toner) can be copied using Black/White Reverse to reduce toner
consumption.
- B/W
Reverse cannot be selected in easy mode.
- B/W Reverse
must be specified before scanning the original.
- When this
function is selected, the "Exposure/Original Type" setting for exposure adjustment
automatically changes to "Text".
When this function is selected, you cannot use
the [Color Start] key.
Tap the [Others] key, and tap the [B/W Reverse] key.
A checkmark appears on the icon.
After the settings are completed, tap the [Back]
key.
To
cancel the B/W reverse setting:
Tap the [B/W Reverse] key to uncheck it.
Place the original.
Place the original in the document feeder tray of the
automatic document feeder, or on the document glass.
AUTOMATIC DOCUMENT FEEDER
DOCUMENT GLASSTo
cancel all settings:
Tap the [CA] key.
Tap the [B/W Start] key to start copying.
You can easily adjust the color and
outlines of images and text.
- Quick Image Quality Adjustment cannot
be selected in easy mode.
- You must select Quick Image Quality Adjustment
before scanning the original.
Tap the [Others] key, and tap the [Quick Image Quality Adjustment] key.
Tap
or slide the slider to adjust the image
quality.
After the settings are completed, tap [OK] key.
To
cancel the quick image quality adjustment setting:
Tap the [Off] key.
Place the original.
Place the original in the document feeder tray of the
automatic document feeder, or on the document glass.
AUTOMATIC DOCUMENT FEEDER
DOCUMENT GLASSTo
cancel all settings:
Tap the [CA] key.
Tap the [Color Start] or [B/W Start]
key to start copying.
This function heightens or lightens any one of the three color components
R (red), G (green), and B (blue).
- RGB cannot be selected in easy mode.
- RGB must be specified before scanning the
original.
Tap the [Others] key, and tap the [RGB Adjust] key.
Tap the key of the color you want to adjust.
Tap
or slide the slider to adjust the coloring.
After the settings are completed, tap [OK] key.
- Only one color can be adjusted.
(If you adjust one color and then tap another color, the
adjustment of the first color is canceled.)
- To cancel
the RGB adjust setting:
Tap the
[Off] key.
Place the original.
Place the original in the document feeder tray of the
automatic document feeder, or on the document glass.
AUTOMATIC DOCUMENT FEEDER
DOCUMENT GLASSTo
cancel all settings:
Tap the [CA] key.
Tap the [Color Start] key to start copying.
This function adjusts the sharpness to make a sharper or softer
image.
- Sharpness cannot be selected in easy
mode.
- Sharpness must be specified before scanning
the original.
Tap the [Others] key, and tap the [Sharpness] key.
Tap
or slide the slider to adjust the sharpness.
Select [More Sharp] for sharper outlines, or [Less Sharp]
for softer outlines.
After the settings are completed, tap [OK] key.
To
cancel the sharpness setting:
Tap the [Off] key.
Place the original.
Place the original in the document feeder tray of the
automatic document feeder, or on the document glass.
AUTOMATIC DOCUMENT FEEDER
DOCUMENT GLASSTo
cancel all settings:
Tap the [CA] key.
Tap the [Color Start] or [B/W Start]
key to start copying.
You can adjust the color, tone, and density of copies.
Use the [Color] tab for color copy settings, or
the [B/W] tab for black & white copy settings.
If you select the [Color] tab, the densities of the colors
yellow, magenta, cyan, and black are divided into three ranges, and
you can adjust the density of each range. If needed, you can also
adjust all three density ranges at once.
- Color Balance cannot be selected
in easy mode.
- Color Balance must be specified before
scanning the original.
Tap the [Others] key, and tap the [Color Balance] key.
Tap the tab of the mode you want to adjust.
Tap the
key or slide the slider to adjust the color balance.
If you want to adjust
each color individually on the [Color] tab, set the [Set in a Batch]
checkmark to
.
If you want to further
adjust each range of each color individually, set the [Set in a Group by Color]
checkbox to
.
To adjust each range
on the [B/W] tab, set the [Set in a Batch] checkbox to
.
To adjust a slider individually
with the
keys, tap the slider you want to adjust
and tap the
keys.
After the settings are
completed, tap [OK] key.
To
return the color balance of the current tab to the default
balance:
Tap the
[Reset] key.
The values
of all gradations currently being adjusted will return to their
default color balance values.
Place the original.
Place the original in the document feeder tray of the
automatic document feeder, or on the document glass.
AUTOMATIC DOCUMENT FEEDER
DOCUMENT GLASSTap the [Color Start] or [B/W Start]
key to start copying.
This function adjusts the brightness of a color copy image.
- Brightness cannot be selected in
easy mode.
- Brightness must be specified before scanning
the original.
Tap the [Others] key, and tap the [Brightness] key.
Tap the
key or slide the slider to adjust the
brightness.
After the settings are completed, [OK] and [Back]
keys in sequence.
To
cancel the brightness setting:
Tap the [Off] key.
Place the original.
Place the original in the document feeder tray of the
automatic document feeder, or on the document glass.
AUTOMATIC DOCUMENT FEEDER
DOCUMENT GLASSTo
cancel all settings:
Tap the [CA] key.
Tap the [Color Start] key to start copying.
This function adjusts the intensity (saturation) of a color copy
image.
- Intensity cannot be selected in easy
mode.
- You must set the intensity before scanning
the original.
This function cannot be combined with [Copy of Copy]
or [Color Tone Enhancement] in Exposure.
Tap the [Others] key, and tap the [Intensity] key.
Tap the
key or slide the slider to adjust the
intensity.
After the settings are completed, tap the [OK]
and [Back] key.
To
cancel the Intensity setting:
Tap the [Off] key.
Place the original.
Place the original in the document feeder tray of the
automatic document feeder, or on the document glass.
AUTOMATIC DOCUMENT FEEDER
DOCUMENT GLASSTo
cancel all settings:
Tap the [CA] key.
Tap the [Color Start] key to start copying.
