PART NAMES AND FUNCTION

Output tray (center tray)*

Printed paper is output into this tray.

Keyboard*

Use this as a substitute for the soft keyboard displayed on the touch panel. When not being used, it can be stored under the operation panel.

NAMES AND FUNCTIONS OF SOFT KEYBOARD KEYS

Automatic document feeder

This automatically feeds and scans multiple originals. Both sides of 2-sided originals can be automatically scanned at one time.

AUTOMATIC DOCUMENT FEEDER

Toner cover (Upper front cover)

Open this cover to replace the toner cartridge or to remove misfed paper in the paper pass unit.

REPLACEMENT OF TONER CARTRIDGE

Front cover

Open this cover to switch the main power switch to "On" or "Off".

TURNING ON THE POWER

CLEANING THE LASER UNIT

Operation panel

This panel hosts the [Power] button, main power indicator, and touch panel. Use the touch panel to operate each of these functions.

OPERATION PANEL

USB connector (A type)

This is used to connect a USB device such as a USB memory device to the machine.
For the USB cable, use a shielded cable.
Supports USB 2.0 (Hi-Speed).

Tray 1

Store paper in this tray. Up to 1200 sheets can be stored.

LOADING PAPER IN THE TRAY 1/2

Tray 3

Store paper in this tray. Up to 500 sheets can be stored.

LOADING PAPER IN THE TRAY 3/4

Tray 4

Store paper in this tray. Up to 500 sheets can be stored.

LOADING PAPER IN THE TRAY 3/4

Tray 2

Store paper in this tray. Up to 800 sheets can be stored.

LOADING PAPER IN THE TRAY 1/2

* Peripheral device.

‹-+›

Finisher (large stacker)*

This staples and outputs paper.

FINISHER (LARGE STACKER)

Saddle stitch finisher (large stacker)*

This staples and folds paper.

SADDLE STITCH FINISHER (LARGE STACKER)

Status indicator*

The status of the machine is indicated.

STATUS INDICATORS

Right tray*

As required, paper can be output into the right tray.

Bypass tray*

Use this tray to feed paper manually.
When loading paper larger than A4R or 8-1/2" × 11"R, pull out the extension guide.

LOADING PAPER INTO THE BYPASS TRAY

Curl correction unit*

This punches and outputs paper.

Tray 5 (MX-LC12)*

Store paper in this tray. Up to 3500 sheets can be stored.

LOADING PAPER IN THE LARGE CAPACITY TRAY

Tray 5 (MX-LCX3 N)*

Store paper in this tray. Up to 3000 sheets can be stored.

LOADING PAPER IN THE LARGE CAPACITY TRAY

* Peripheral device.

‹-+›

Punch module*

This punches and outputs paper.

Inserter*

Covers and insertion sheets to be inserted into printed sheets can be loaded.
Using the manual finishing function, you can directly feed paper into the finisher or saddle stitch finisher to staple, punch or fold the paper.

Bypass tray*

Use this tray to feed paper manually.
When loading paper larger than A4R or 8-1/2" × 11"R, pull out the extension guide.

LOADING PAPER INTO THE BYPASS TRAY

Trimming module*

This trims the excess of saddle-stitched output.

Folding unit*

This folds and outputs paper.

Paper pass unit*

This feeds paper to the machine.

Large capacity trays*

Store paper in this tray. Up to 2500 sheets can be stored in each tray.

LOADING PAPER IN THE LARGE CAPACITY TRAYS

* Peripheral device.

Toner cartridge

This cartridge contains toner.
When the toner in a cartridge runs out, the cartridge of the color that ran out must be replaced.

REPLACEMENT OF TONER CARTRIDGE

Fusing unit

Heat is applied here to fuse the transferred image onto the paper.

Caution

The fusing unit is hot. Take care not to burn yourself when removing a misfeed.

Right side cover

Open this cover to remove a misfeed.

Paper reversing section cover

This unit is used for reversing paper when 2-sided printing is performed. Open this cover to remove a paper misfeed.

The main power switch

Use this switch to turn on the power for the machine.

TURNING ON THE POWER

Toner collection container

This container collects excess toner that remains after printing.

REPLACING THE TONER COLLECTION CONTAINER

A service technician collects replaced toner collection container.

Transfer belt

This belt takes the image formed with toner off the photoconductive unit and transfers the image onto paper.

Caution

Do not touch or damage the transfer belt. This may cause a defective image.

Right side cover release lever

To remove a paper misfeed, pull and hold this lever up to open the right side cover.

Paper feed roller

This roller rotates to automatically feed the original.

Document feeding cover

Open this cover to remove an original misfeed.
This cover is also opened to clean the paper feed roller.

CLEANING THE PAPER FEED ROLLER

Original guides

These guides help ensure that the original is scanned correctly.
Adjust the guides to the width of the original.

Document feeder tray

Place the original.
Place the original with the print side facing up.

AUTOMATIC DOCUMENT FEEDER

Original exit tray

The original is discharged to this tray after scanning.

Original setting indicator

This indicator lights when the document is correctly loaded on the document feeder tray.

ORIGINAL SETTING INDICATOR

Scanning area

Originals placed in the automatic document feeder are scanned here.

CLEANING THE DOCUMENT GLASS AND AUTOMATIC DOCUMENT FEEDER

Original size detector

This unit detects the size of an original placed on the document glass.

DOCUMENT GLASS

Document glass

If you want to scan books or other thick originals that cannot be fed through the automatic document feeder, place them on this glass.

DOCUMENT GLASS

USB connector (A type)

This is used to connect a USB device such as a USB memory device to the machine.
Supports USB 2.0 (Hi-Speed) and USB3.0 (SuperSpeed).

USB connector (B type)

Cannot be used.

LAN connector

Connect the LAN cable to this connector when the machine is used on a network.
Use a shielded LAN cable.

Power plug

This section describes the names and functions of the respective parts of the operation panel.

Touch panel

Messages and keys appear on the touch panel display.
Operate the machine by directly tapping the displayed keys.

BEFORE USING THE MACHINE

Main power indicator

This indicator lights up when the machine's main power switch is in the “ ” position.
Blinks blue during the time that the [Power] button does not operate immediately after the main power switch is switched on.
This indicator will also blink blue when receiving printer data.
This indicator blinks yellow during Auto Power Shut-Off mode.

TURNING ON THE POWER

[Power] button

Use this button to turn the machine's power on and off.

TURNING ON THE POWER

USB connector (A type)

This is used to connect a USB device such as a USB memory device to the machine.

Supports USB 2.0 (Hi-Speed).
